Quick Start Guide
D103556X012
DVC6200 Digital Valve Controllers
August 2015
59
Intrinsically safe when connected per control drawing GE60771, as shown in the following figures
DVC6200 HW1 figure 49 and 54...........................................
DVC6200 HW2, DVC6200 SIS figure 50 and 54...............................
DVC6205, DVC6205 SIS, and DVC6215 Remote Mount figure 51 and 54........
DVC6200f and DVC6200p figure 52 and 54..................................
DVC6205f, DVC6205p, and DVC6215 Remote Mount figure 53 and 54..........
Special Conditions for Safe Use; Intrinsically Safe Applications
D This apparatus can only be connected to an intrinsically safe certified equipment and this combination must be
compatible as regards the intrinsically safe rules.
D Covered by standards EN 600790 (2009), EN 6007911 (2012), EN 6007926 (2007).
D For the model with aluminum body: the apparatus must not be submitted to frictions or mechanical impacts.
GE60771 sheet 3, Rev. B
ATEX APPROVED BARRIER
1 NOTE 1, 3, 4
1 NOTE 5
ZONE 0, Ex ia IIC
ZONE 20, Ex ia IIIC
Ui = 30 VDC
Ii = 226 mA
Ci = 5 nF
Li = 0.55 mH
Pi = 1.4 W
NON‐HAZARDOUS LOCATION
HAZARDOUS LOCATION
Figure 49. ATEX Loop Schematic—FIELDVUE DVC6200 HW1
1 SEE NOTES IN FIGURE 54
T CODE T AMB
MAX SURFACE
TEMP
T AMB
T5 ≤ 80_C
T6 ≤ 75_C
T85_C ≤ 76_C
T89_C ≤ 80_C
ZONE 20, Ex ia IIIC
ZONE 0, Ex ia IIC
DVC6200, DVC6200S
