FloBoss 103/104 Instruction Manual
Revised August-2017 Installation and Use 2-13
procedures in a hazardous area could result in personal injury or
property damage.
During operation, you can monitor the FB100 (to view or retrieve
current and historical data) either locally or remotely. Accomplish local
monitoring either by viewing the LCD panel or by using ROCLINK 800
software on a PC connected through the LOI port. Remote monitoring is
performed through Comm 1 or Comm 2 of the FB100 using ROCLINK
800 software or a host system.
2.5 Configuration
The FB100 has a number of software settings, called parameters, which
you must configure before you can calibrate the device and place it into
operation. Use ROCLINK 800 configuration software for this purpose.
Normally, you connect a PC running ROCLINK 800 to the LOI port of
the FB100 and transfer configuration data into the FB100, although you
can perform much of the configuration off-line and download it later
into the unit.
The FB100 firmware provides default values for all parameters. If the
default values are acceptable for your application, you can leave the
values as you found them. Refer to the ROCLINK 800 Configuration
Software User Manual (Part D301159X012).
