FloBoss 103/104 Instruction Manual
1-4 General Information Revised August-2017
A
Field conduit entry
B
Optional solar panel mounts here
C
Liquid crystal display (LCD)
D
Dual variable sensor (DVS)
Figure 1-1. FloBoss 103 Flow Manager with LCD
A
Liquid crystal display (LCD)
B
Pulse interface module
C
Optional solar panel
D
Pressure transducer
Figure 1-2. FloBoss 104 Flow Manager with Solar Panel
