Installation
Section 2: Installation
Section 2: Installation
To assemble the OM1 into the EPI2 actuator, proceed as follows:
• Ensure that all the parts received with the OM1 are available as described in
Section 5.
• Using Section 5, select only mechanical parts (screws and spacers) depending on
actuator models.
• Gather the right tools for the assembly and for setting the actuator controls.
• With an Allen wrench of 5 mm, unscrew the cover screws as shown in Figure 1.
• Remove the actuator cover as shown in Figure 2.
Figure 2
Figure 1
Follow one of the following assembling procedures depending on actuator model.
To Next Page
