User Manual 10H52188UM60 - Rev. 2 - 09/2012 7
Liebert NX Product Introduction
UPS module rear panel
As shown in Figure 1-3 and Figure 1-4, the UPS module rear panel provides parallel ports, Load Bus Synchronization (LBS) ports,
Intellislot cards port, dry contact ports, opto-coupled ports, USB port and ventilation holes. The SIC-SNMP card in the
Intellislot cards port is optional, it is sold separately.
Figure 1-3 UPS module rear panel
Figure 1-4 User dry contact and opto-coupled connectors
Note
Non-authorized personnel are prohibited from opening the UPS chassis cover.
Parallel port
LBS port
Intelligent card
port (with
protective cover)
Dry contact port
and opto-coupled ports
USB port
Ventilation hole
