Product Introduction Liebert NXC
1.3 Appearance And Components
1.3.1 Appearance
The UPS device appearance is shown in Figure 1-1.
Front view Rear view
Figure 1-1 UPS appearance
1.3.2 Components
UPS module front panel
As shown in Figure 1-2, the UPS module front panel provides ventilation holes, operation and display panel, LED indicators, DIP
switch and battery cold start button.
Figure 1-2 UPS module front panel
Ventilation hole
Operation and display panel
LED indicator
DIP switch and battery
cold start button (with
protective cover)
