104 Micro Motion Series 1000 and Series 2000 Transmitters
Measurement Performance
Figure 10-3 Meter verification test, original version – Communicator
10.3.3 Running Smart Meter Verification
To run a Smart Meter Verification test:
• With ProLink II, see Figure 10-4.
• With the display, see Figures 10-5 and 10-6.
• With the 375 Field Communicator, see Figure 10-7.
Note: If you start a Smart Meter Verification test from ProLink II or the Communicator, and the
outputs are set to Last Measured Value or Fault, the transmitter display shows the following message:
SENSOR
VERFY/x%
Meter verification
completed: x%
(2)
UNSTABLE FLOW
(1)
Meter verification
FAILED
Meter verification
CAUTION
Correct condition
Choose output setting
On-Line Menu >
3 Diag/Service >
3 Calibration >
3 Meter verification
Set stiffness setpoint
Meter verification
PASS
(1) Either Unstable Flow or Unstable Drive Gain may be displayed, indicating that the
standard deviation of the flow or drive gain is outside limits.
(2) Represents the percentage completion of the procedure.
