Barrier terminalsFigure 3-9:
A. I.S. terminals for connection to enhanced core processor
B. Non I.S. terminals for connection to remote host and power supply
2. Terminate the shields at the remote host.
Do not add external resistors. The barrier contains internal pull-up/pull-down and
termination resistors.
Wiring
Quick Start Guide 19
