7
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: 42-ANT & 52-ANT
3. Installing the Hanger Ball/Downrod Assembly
(For Standard Mounting) (Continued)
HANGER BALL/
DOWNROD
ASSEMBLY
6 to 9
INCHES
3.5
The fan comes with blue, black and white leads that are
42” long.
Measure up approximately 6 to 9-inches above top of
hanger ball/downrod assembly (Figure 5).
Cut off excess leads and strip back insulation 1/2-inch
from end of leads.
Figure 5
To Next Page
