Emerson PRO Series User Manual

12. Installing the Light Fitter and Glass (Continued)
F
AN SWITCH
P
ULL CHAIN
LIGHT FITTER
ASSEMBLY
BOWL CAP BUSHING
FINIAL NUT
OUTER BOWL CAP
Figure 33
12.10
R
emove the Finial Nut and Outer Bowl Cap from the
Light Fitter Assembly (Figure 33).
P
ass the Fan Switch Pull Chain through the Bushing in
the Bowl Cap (Figure 33).
OUTER BOWL CAP
GLASS BOWL
FINIAL NUT
Figure 34
12.11
Position the Glass Bowl over the Threaded Nipple and
seat Bowl on Bowl Cap (Figure 34).
Pass the Fan Pull Chain through the Bushing in the
Outer Bowl Cap and install the Cap on the Threaded
Nipple. Install Finial Nut finger tight.
CAUTION
Be sure that the fan switch chain does not make
contact with the light bulbs. If necessary reposition
the light fitter to avoid the fan switch chain from
touching the light bulbs.
PENDANTS (2)
COUPLINGS (2)
CEILING FAN SPEED
SWITCH PULL CHAIN
LIGHT FITTER ASSEMBLY
PULL CHAIN
Figure 35
12.12
Install Pendants onto Light Fitter Assembly Pull Chain
and Ceiling Fan Speed Switch Pull Chain using
Couplings provided (Figure 35).
NOTE: It is advisable to periodically check the
tightness of the finial.
To avoid possible fire hazard, do not exceed wattage
indicated on the fitter.
WARNING
!
21
emersonfans.com
Please contact 1-800-654-3545 for further assistance
U.L. Model No.: 52-ANT
