Emerson Rosemount 644 with HART Protocol User Manual

Field Communicator Menu Trees and Fast Keys
July 2018
Reference Manual
00809-0200-4728, Rev SA
Field Communicator Menu Trees and Fast Keys
92
Figure B-4. Rosemount 644 HART
®
Revision 7 Field Communicator Menu Tree – Overview
Home
1 Overview
2 Configure
3 Service Tools
Overview
1 Device Status
2 Comm Status
3 Primary Variable
4 Sensor Values/Status
5 Analog Output Value
6 Upper Range Value
7 Lower Range Value
8 Device Information
Options Ordered
1 Dual Sensor Option
2 Hot BU and Sensor Drift
3 T/C Diag & Min/Max
Good (only if No Alerts)
1 No Active Alerts
Advisory
1 Calibration Error
Active Alerts
1 Good (only if No Alerts)
2 Failed
3 Advisory
4 Maintenance (Fix Soon)
Alarm Type and Security
1 Alarm Direction
2 High Saturation
3 Low Saturation
4 High Alarm
5 Low Alarm
6 Software Write Protect
7 Lock Status
8 Password Protection
Identification
1 Tag
2 Long Tag
3 Model
4 Electronics S/N
5 Final Assembly Num
6 Date
7 Description
8 Message
9 Device Image
Failed
1 Invalid Configuration
2 Electronics Failure
3 Calibration Error
4 Sensor Drift Alert Active
5 Sensor 1 Open
6 Sensor 2 Open
7 Sensor 1 Shorted
8 Sensor 2 Shorted
9 Terminal Temp Failure
Maintenance
1 Hot Backup Active
2 Sensor Drift Alert Active
3 Sensor 1 Degraded
4 Sensor 2 Degraded
5 Excess EMF
6 Sensor 1 Out of Operating Range
7 Sensor 2 Out of Operating Range
8 Terminal Temp Out of Range
9 Analog Output Saturated
10 Analog Output Fixed
Device Information
1 Identification
2 Revisions
3 Alarm Type and Security
4 Options Ordered
Revisions
1 HART Universal Rev
2 Field Device
3 Hardware
4 Software
5 DD Revision
