Figure B-3. Service Tools
Home
1 Overview
2 Configure
3 Service Tools
Trends
1 Sensor 1
2 Sensor 2
3 Differential
4 Average
5 Terminal Temperature
6 First Good
Analog Calibration
1 Analog Trim
2 Scaled Trim
Fourth Variable
1 Fourth Variable
2 Parameter
3 Status
Third Variable
1 Third Variable
2 Parameter
3 Status
Second Variable
1 Second Variable
2 Parameter
3 Status
Primary Variable
1 Primary Variable
2 Parameter
3 Status
Simulate
1 Perform Loop Test
2 Device Variables
Analog Output
1 Analog Output Value
2 AO Gauge
Thermocouple Diag Sensor X
1 Resistance
2 Sensor X Status
3 Threshold Exceeded
4 TC Diag Config
Sensor Calibration
1 Calibrate Sensors
2 Restore Facotry Cal
3 Sensor 1 Lower Cal
4 Sensor 1 Upper Cal
5 Sensor 2 Lower Cal
6 Sensor 2 Upper Cal
7 Active Calibrator
Active Alerts
1 Good (only if No Alerts)
2 Failed
3 Advisory
4 Maintenance (Fix Soon)
Service Tools
1 Alerts
2 Variables
3 Trends
4 Maintenance
5 Simulate
Variables
1 Variable Summary
2 Primary Variable
3 Second Variable
4 Third Variable
5 Fourth Variable
6 Analog Output
Min/ Max Tracking
1 Min/Max Mode
2 Reset All Min/Max Values
3 Parameter 1
4 Parameter 2
5 Parameter 3
6 Parameter 4
Maintenance
1 Thermocouple Diag Snsr 1
2 Thermocouple Diag Snsr 2
3 Min/Max Tracking
4 Sensor Calibration
5 Analog Calibration
Good (only if No Alerts)
1 No Active Alerts
Failed
1 Invalid Configuration
2 Electronics Failure
3 Calibration Error
4 Sensor Drift Alert Active
5 Sensor 1 Open
6 Sensor 2 Open
7 Sensor 1 Shorted
8 Sensor 2 Shorted
9 Terminal Temp Failure
Advisory
1 Calibration Error
Maintenance
1 Hot Backup Active
2 Sensor Drift Alert Active
3 Sensor 1 Degraded
4 Sensor 2 Degraded
5 Excess EMF
6 Sensor 1 Out of Operating Range
7 Sensor 2 Out of Operating Range
8 Terminal Temp Out of Range
9 Analog Output Saturated
10 Analog Output Fixed
To Next Page
