Emerson Rosemount 644 with HART Protocol User Manual

33
Reference Manual
00809-0200-4728, Rev SA
Configuration
July 2018
Configuration
Field Communicator
From the HOME screen, enter the Fast Key sequence.
AMS Device Manager
1. Right click on the device and select Configure.
2. In the left navigation window select Manual Setup.
3. On the Diagnostics tab, there is a group box labeled Sensor and Process Diagnostics; select the
button for Configure Thermocouple Diagnostic.
4. Follow the screen prompts to Enable and set the values for the diagnostic.
AMS terms
Resistance: This is the existing resistance reading of the thermocouple loop.
Resistance threshold exceeded: The check box indicates if the sensor resistance has passed the Trigger
Level.
Trigger level: Threshold resistance value for the thermocouple loop. The trigger level may be set for 2, 3,
or 4  Baseline or the default of 5000 Ohms. If the resistance of the thermocouple loop surpasses the
Trigger Level, a maintenance alert will be generated.
Baseline resistance: The resistance of the thermocouple loop obtained after installation, or after
resetting the baseline value. The trigger level may be calculated from the baseline value.
Reset baseline resistance: Launches a method to recalculate the Baseline value (which may take several
seconds).
TC diagnostic mode sensor 1or 2: This field will read either enabled or disabled indicating when the
thermocouple degradation diagnostic is on or off for that sensor.
LOI
Reference the Figure 2-21 to find the path to the thermocouple diagnostic in the LOI menu.
Figure 2-21. Configuring T/C Diagnostic with LOI
* Available only if option code (S) or (D) is ordered.
Device Dashboard Fast Keys
2, 2, 4, 3, 4
CALIBRAT
DAMPING
VARIABLE MAP
TAG
ALM SAT VALUES
PASSWORD
SIMULATE
HART REV
HOT BACK CONFIG*
DRIFT ALERT*
TC DIAG CONFIG
TC DIAG CONFIG
MIN MAX TRACK
BACK TO MENU
EXIT MENU
CONFIG SNSR 1CONFIG SNSR 1
CONFIG SNSR 2*
BACK TO MENU
EXIT MENU
VIEW CONFIG
SENSOR CONFIG
UNITS
RERANGE
LOOP TEST
DISPLAY
EXTENDED MENU
EXTENDED MENU
EXIT MENU
SENSOR 1 MODE
TRIGGER CONFIG
TRIGGER VIEW
SNSR OHM VIEW
BASELINE RE-SET
BASELINE VIEW
BACK TO MENU
EXIT MENU
