Emerson Rosemount 8800D Series User Manual

Figure 2-5: Upstream/Downstream piping
A
C
B
D
A. Pressure transmitter
B. Four straight pipe diameters downstream
C. Temperature transmitter
D. Six straight pipe diameters downstream
2.1.7 Wafer style installation
Figure 2-6: Wafer style installation
C
A
B
B
D
A. Installation studs and nuts (supplied by customer)
B. Alignment ring
C. Gaskets (supplied by customer)
D. Flow direction
Quick Start Guide October 2018
8 Rosemount
™
8800D Series Vortex Flowmeter
