124 Unidrive SP Regen Installation Guide
www.controltechniques.com Issue Number: 2
Table 9-13 Temperature thresholds for fan operation
This value can be used to trim out any offset from the user input signal
Drive size Fan threshold Lower fan threshold Upper fan threshold
SP0xxx TBA N/A N/A
SP1xxx 60 N/A N/A
SP2xxx 60 N/A N/A
SP3xxx N/A 55 70
SP4xxx N/A 55 62
SP5xxx N/A 55 62
SP6xxx N/A 55 65
SPMxxxx N/A 55 65
7.07 T5/6 analogue input 1 offset trim
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
311
Range Regen ±10.000 %
Default Regen 0.000
Update rate Background
7.08 T5/6 analogue input 1 scaling
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range Regen 0.000 to 4.000
Default Regen 1.000
Update rate Background
7.09 T5/6 analogue input 1 invert
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate Background read
7.10 T5/6 analogue input 1 destination
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Regen Pr 0.00 to Pr 21.51
Default Regen Pr 0.00
Update rate Background
