The following modes are available for the analogue outputs.
In voltage mode the output range is -10V to 10V. If the scaling parameter is 1.000 then -10V and 10V are produced when the source parameter is at -
maximum and maximum respectively. Different scaling can be applied with Pr 7.23. If the result of the scaling produces an output of more than +/-
100% the output is clamped within the +/-10V range.
In current modes with a scaling parameter of 1.000 the minimum and maximum current are produced when the source parameter is at 0 and
maximum respectively. Therefore in 4 - 20mA mode the output is 4mA when the source parameter is zero. Different scaling can be applied with
Pr 7.23. If the result of the scaling produces an output of more than 100% the output is clamped at 20mA
If high speed update mode is selected and the source for the output is one of the parameters designated for high speed analogue output operation
(see start of this section) the output is updated at a higher rate with special scaling. If the parameter selected is not designated for this mode the
output is updated at the normal rate. If speed feedback or power is selected for high speed mode for both analogue output 1 and analogue output 2
the setting is ignored for analogue output 2. If the high speed mode is selected the output is always a voltage signal.
Setting this bit will cause the drive to re-calibrate the full scale level of analogue input 1 provided the input voltage is below +1.5V or above +2.5V. This
parameter is cleared by the software automatically when the calibration is complete. If the input voltage is above +2.5V the input voltage itself is used
for calibration, and so after calibration this level will be full scale for the input. If the input voltage is below +1.5V the internal reference is used for
calibration, and so the full scale will be nominally 9.8V after calibration. The calibration level is automatically stored on power-down. It should be noted
that the Analogue input 1 offset trim is included in the input voltage when the input voltage itself is used for calibration, but this trim is not included
when the internal reference is used for calibration.
Analogue input 1 is filtered using a window filter to remove quantisation noise and adjust the resolution of this input. The length of the window can be
adjusted with this parameter. The shortest possible window is 250µs. It should be noted that if this input is not used as a speed reference (Pr 1.36,
Pr 1.37) or as a hard speed reference ({Pr 3.22) the sample time affects the resolution. The nominal resolution is given by Pr 7.26 x 500 x 103,
therefore the default setting gives approximately 11 bit resolution.
7.24 T10 analogue output 2 mode
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range Regen 0 to 3
Default Regen 0
Update rate Background
Parameter value Parameter string Mode
0 VOLt Voltage mode
10-20 0 - 20mA
24-20 4 - 20mA
3 H.Spd High speed up date mode
7.25 Calibrate T5/6 analogue input 1 full scale
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate Background
7.26 T5/6 analogue input 1 sample time
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range Regen 0 to 8.0 ms
Default Regen 4.0
Update rate Background
