94 Unidrive M / HS Frame 7 to 10 Power Installation Guide
Issue Number: 5
5.1.3 Power dissipation
Table 5-7 Losses @ 40° C (104° F) ambient
Model
Normal Duty Heavy Duty
Nominal
rating
Drive losses (W) taking into account any
current derating for the given conditions
Nominal
rating
Drive losses (W) taking into account any
current derating for the given conditions
kW hp
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
kW hp
2
kHz*
3
kHz
4
kHz
6
kHz
8
kHz
12
kHz
16
kHz
200 V
07200610 18.5 25 533 570 597 650 703 885 894 15 20 433 466 488 532 575 666 715
07200750 22 30 671 718 751 815 881 890 899 18.5 25 529 570 597 650 703 710 717
07200830 30 40 851 911 951 1004 911 920 929 22 30 589 634 663 720 755 763 770
08201160 37 50 1339 1433 1536 1765 1943 1962 1982 30 40 1026 1105 1193 1343 1373 1387 1401
08201320 45 60 1638 1753 1894 1914 1985 2005 2025 37 50 1260 1269 1306 1349 1372 1386 1400
09201760 (9A) 55 75 2028 2170 2312 2596 2448 2160 2031 45 60 1580 1701 1822 2065 2022 1881 1820
09202190 (9A) 75 100 2585 2754 2822 2623 2448 2156 2034 55 75 2016 2160 2227 2107 2025 1874 1821
09201760 (9E) 55 75 1889 2031 2174 2458 2348 2112 2006 45 60 1488 1609 1730 1973 1952 1845 1801
09202190 (9E) 75 100 2375 2554 2625 2482 2348 2108 2009 55 75 1874 2017 2093 2011 1956 1839 1802
10202830 90 125 2478 2672 2867 3123 2952 2701 2554 75 100 2068 2240 2413 2561 2494 2376 2303
10203000 110 150 2802 3016 3230 3126 2957 2706 2554 90 125 2213 2394 2576 2561 2494 2389 2323
400 V
07400660 37 60 745 830 907 1062 1218 1230 1242 30 50 616 692 758 773 763 771 778
07400770 45 60 896 999 1088 1264 1241 1253 1266 37 60 723 812 802 800 811 819 827
07401000 55 75 1033 1152 1247 1218 1170 1182 1194 45 75 906 1017 968 936 907 916 925
08401340 75 100 1482 1652 1817 2154 2121 2142 2164 55 100 1224 1374 1509 1521 1510 1525 1540
08401570 90 150 1798 2004 2191 2333 2279 2302 2325 75 125 1373 1541 1670 1674 1673 1690 1707
09402000 (9A) 110 150 2431 2710 2989 3075 2992 2842 2833 90 150 2132 2136 2370 2492 2475 2501 2538
09402240 (9A) 132 200 3016 3191 3143 3063 3000 2856 2828 110 150 2424 2532 2511 2489 2474 2498 2537
09402000 (9E) 110 150 2286 2565 2844 2966 2917 2807 2815 90 150 2014 2039 2274 2418 2425 2476 2526
09402240 (9E) 132 200 2806 2998 2984 2955 2925 2821 2811 110 150 2275 2400 2403 2416 2424 2473 2525
10402700 160 250 3210 3582 3954 4148 4034 3939 3843 132 200 2604 2923 3242 3401 3391 3438 3469
10403200 200 300 3703 4121 4226 4154 4038 3947 3874 160 250 3166 3376 3393 3398 3419 3442 3485
575 V
07500440 45 50 867 1004 1139 1358 1262 1275 1287 30 40 700 817 929 1028 967 977 986
07500550 55 60 1078 1248 1375 1209 1122 1133 1145 37 50 759 886 1002 914 863 872 880
08500630 75 75 1607 1861 2180 2814 2982 3012 3042 45 60 1153 1345 1585 2136 2284 2307 2330
08500860 90 100 2050 2374 2753 2947 2963 2993 3023 55 75 1554 1813 2174 2212 2218 2240 2263
Unidrive M frame7 to 10 Power Installation Guide issue5.book Page 94 Tuesday, May 24, 2016 11:52 AM
