11 – 14
Section 11 • Alarms, Trips, Status Information & Troubleshooting
Blower Package PLC Operation Manual •Vilter/Emerson • 35391BLP
Trip Message Cause(s) Notes
(T107) Alarm: Lower Inlet Scrubber
High High Level
Inlet Scrubber Lower Section High
High Liquid Level Switch Activated
(Selected Action = TRIP)
Active if Coalescing Type Inlet
Scrubber is present
(T108) Trip: (Unassigned)
(T109) Trip: (Unassigned)
(T110) Trip: (Unassigned)
(T111) Alarm: Outlet Scrubber High
High Level
Outlet Scrubber High High Liquid
Level Switch Activated (Selected
Action = TRIP)
Active if Vane Type Outlet Scrubber
is Present
(T112) Alarm: Outlet Scrubber Low
Low Level
Outlet Scrubber Low Low Liquid
Level Switch Activated (Selected
Action = TRIP)
Active if Vane Type Outlet Scrubber
is Present
(T113) Trip: (Unassigned)
(T114) Alarm: Upper Outlet
Scrubber High High Level
Outlet Scrubber Upper Section High
High Liquid Level Switch Activated
(Selected Action = TRIP)
Active if Coalescing Type Outlet
Scrubber is present
(T115) Trip: (Unassigned)
(T116) Trip: (Unassigned)
(T117) Alarm: Lower Outlet Scrubber
High High Level
Outlet Scrubber Lower Section High
High Liquid Level Switch Activated
(Selected Action = TRIP)
Active if Coalescing Type Outlet
Scrubber is present
(T118) Trip: (Unassigned)
(T119) Trip: (Unassigned)
(T120) Trip: Out Of Range: Suction
Header Pressure
Pressure Instrument is Disconnected
or Raw Value is less than 3.5 mA or
greater than 20 mA
Active if Suction Header Pressure is
Being Monitored
(T121) Trip: Out Of Range: Blower 1
Suction Pressure
Pressure Instrument is Disconnected
or Raw Value is less than 3.5 mA or
greater than 20 mA
(T122) Trip: Out Of Range: Blower 1
Discharge Pressure
Pressure Instrument is Disconnected
or Raw Value is less than 3.5 mA or
greater than 20 mA
(T123) Trip: Out Of Range: Blower 1
Discharge Temperature
RTD Input is Disconnected or Raw
Value is less than 3.5 mA or greater
than 20 mA (If using 4-20mA
Transmitter)
(T124) Trip: Out Of Range: Blower 1
Phase A Temperature
RTD Input is Disconnected or Raw
Value is less than 3.5 mA or greater
than 20 mA (If using 4-20mA
Transmitter)
Active if Winding Temperatures are
being monitored.
(T125) Trip: Out Of Range: Blower 1
Phase B Temperature
RTD Input is Disconnected or Raw
Value is less than 3.5 mA or greater
than 20 mA (If using 4-20mA
Transmitter)
Active if Winding Temperatures are
being monitored.
(T126) Trip: Out Of Range: Blower 1
Phase C Temperature
RTD Input is Disconnected or Raw
Value is less than 3.5 mA or greater
than 20 mA (If using 4-20mA
Transmitter)
Active if Winding Temperatures are
being monitored.
To Next Page
