Table 5-2: Predefined Modbus Registers (continued)
Description Register Data type
SYSTEM_DIAG.TEST_UNSIGNED_BYTE 49033 8-bit unsigned int
SYSTEM_DIAG.TEST_SHORT 49034 16-bit int
SYSTEM_DIAG.TEST_UNSIGNED_SHORT 49035 16-bit unsigned int
SYSTEM_DIAG.TEST_INT 49036 32-bit int
SYSTEM_DIAG.TEST_UNSIGNED_INT 49038 32-bit unsigned int
SYSTEM_DIAG.TEST_FLOAT 49040 32-bit float
5.5 EtherNet/IP
5.5.1 EtherNet/IP Communication settings
It is important that the Ethernet/IP communication settings in the Gateway match the
setting in the Ethernet/IP master or client. Refer to host system documentation for more
information on how to configure these settings or to the Emerson Wireless Gateway
Integration Reference Manual for Ethernet/IP. The Ethernet/IP communication settings
can be found by navigating to System Settings → Protocols → EtherNet/IP. Network
architectures should reflect that of a DeltaV
™
system see #unique_72/
unique_72_Connect_42_Ram24704.
Note
Ethernet/IP can be integrated with any approved Ethernet/IP ODVA member. Other
protocols such as HARTIP are still functional within the Gateway. See the Emerson Wireless
Gateway Product Data Sheet for ordering options.
Reference Manual Operation and Maintenance
00809-0200-4420 September 2020
Emerson.com/Rosemount 53
