Table D-1: Redundancy Diagnostics (continued)
Parameter Description Data type
REDUNDANT_A_MAS
TER
Indication if Gateway A is the active system Boolean
REDUNDANT_A_PING Indication if Gateway A is able to ping designated host IP address Boolean
REDUNDANT_A_ETH0 Electrical connection status of the primary Ethernet port for Gateway A 8-bit unsigned int
REDUNDANT_B_ONLI
NE
Operational status of Gateway B Boolean
REDUNDANT_B_MAS
TER
Indication if Gateway B is the active system Boolean
REDUNDANT_B_PING Indication if Gateway B is able to ping designated host IP address Boolean
REDUNDANT_B_ETH0 Electrical connection status of the primary Ethernet port for Gateway A 8-bit unsigned int
D.5.1 Configure network connectivity
In addition to the redundancy diagnostics, an additional check may be configured to test
network connectivity to a host system or other application. The redundant system will use
this check to determine the best connectivity option and which Gateway should be set to
the active Gateway.
To configure network connectivity check:
Procedure
1. Navigate to System Settings → Gateway → Ethernet Communication.
2. Enter the host system IP address in the Check Network Connectivity IP Address field.
3. Select Save Changes.
