EMI S1CG - Page 7

S1CG/S1HG
S
in
g
le-Zone, S2CG/S2H
G
Dual-Zone
•
I
nstallation,
Op
eration and Maintenance Manual •
P/N 240007754, Rev. C [3/19/2010] 7 Made in the USA
Mounting the Unit (continued)
Remove front panel screwsFigure 1
1 2
Remove front panelFigure 2
Bottom lag hole locationsFigure 3
A
A
A
A
B
B
C
C
D
D
E
E
S1CG
S1CG
Shown
Shown
Lag boltsA Filter drierB
CompressorC AccumulatorD
CapacitorE
Lag holes in feetFigure 4
S1CG
S1CG
Shown
Shown
