6.2.6 ALARM Output-1 Configuration Parameters
It determines logic output function for Alarm Output-1
It determines alarm type for Output-1. It is active if logic output function
of Alarm Output-1 is alarm output.
Alarm output
Sensor break alarm output
Manual / Automatic data output
58
Process high alarm
Process low alarm
Deviation high alarm
HYS
ON
OFF
Process
Set
Process Set + Alarm Set
HYS
ON
OFF
Alarm
Set
HYS
ON
OFF
Alarm
Set
Output is active when the process value is out of the band
which is defined with minimum value of operating scale
And maximum value of operating scale
Process high alarm
Process low alarm
Deviation high alarm
Deviation low alarm
Deviation band alarm
Deviation range alarm
Process Value
Process Value
Process Value
Alarm
Output
Alarm
Output
Alarm
Output
