EMS FIRECELL Setup Guide

3 Assign the RCCs
TX
RESET
LOGON
RX
BACK
HEALTHY
FA U LT
SYS FAULT
LOOP 1
+
-
IN OUT IN OUT
+
-
LOOP 2
+
-
IN OUT IN OUT
+
-
LOOP 3
+
-
IN OUT IN OUT
+
-
LOOP 4
+
-
IN OUT IN OUT
+
-
RF1 RF2
TX
RX
Assign Device
The newly added RCCs should now be assigned.
From Unassigned Dev Assign Device Dev 000 of 001 changing to Done
001 of 001 (once complete).
To Exit
BACK
5

EMS FIRECELL Specifications

General

Frequency	868 MHz
Operating Temperature	-10°C to +55°C
Communication	Wireless
Compliance	EN54-25
Devices Supported	Sounders
Power Supply	Lithium battery
Humidity Range	Up to 95% RH, non-condensing
Compatibility	EMS Firecell System
Type	Wireless Fire Alarm
