EL4.0
Nominal Hydrogen Production
0.3 Nm
3
/h –0.5 Nm
3
/h
1.0785 kg/24 h
Output Pressure
Up to 35 barg
Hydrogen Output Purity
35bar: ~99.9 % (H
2
O: 1000-1500 ppm)
8bar: > 9000 ppm H
2
O
Water Consumption
0.42 l/h
Water Input Conductivity
< 20 µS/cm (at 25 °C), <5 µS/cm (at 25 °C) recommended
Water Input Pressure Range
1 – 4 barg
Process Liquid
1 % KOH solution
Device to be filled with 1.54 % KOH
Operative Power Consumption
2.4 kW (max. 3.1 kW)
Peak Power Consumption
3.1 kW
Nominal Power Consumption
per Nm
3
of H
2
produced
4.8 kWh/Nm
3
(beginning of life)
Stand-by Power Consumption
15 W
Power Supply
220 V – 230 V (AC), 50/60 Hz
48 V – 60 V (DC)
Maximum Heat Dissipation
1.3 kW
Circuit Breaker
C13
Dimensions (W x H x D)
482 mm x 266 mm x 635 mm
Space inside cabinet
6 U
Weight
42 kg (empty)
1
41 kg (empty)
2
Control System Included
EMS
Communications
Wi-Fi
- 802.11a/b/g/n (2.4 GHz only)
- 802.12 WEP, WPA, WPA2 Personal (Pre-shared key)
- Wi-Fi client isolation must be disabled
Bluetooth
Modbus TCP via Ethernet
Remote Control
Enapter Cloud Service, Enapter App, Modbus TCP, Safety chain
(dry contact)
Safety
Maximum H
2
contained within
20 NL
Conformity
Machinery Directive and relevant harmonised standards:
2006/42/CE; ISO 12100
Low Voltage Directive and relevant harmonised standards: LVD
2014/35/UE; EN IEC 61010-1
EMC directive and harmonized standards: EMC 2014/30/UE;
IEC 61326-1
Radio equipment directive and harmonized standards: RED
2014/54/UE; EN 300 328
