6. Getting Start with Wireless Router
6.1 Know the 802.11g Wireless Router
Ports:
● Power Receptor
● Reset Button
● RJ-45 Ethernet Port
Cross-over cable is required to connect to computer directly
● There is no visual LAN port for Pocket AP.
LEDs:
● Power LED: ON when the unit is powered up
● LAN LED: ON indicates LAN connection; BLINK indicates LAN activity
● WLAN LED: ON indicates WLAN is working; BLINK indicates wireless
activity.
6.2 Connect to the 802.11g Wireless Router
6.2.1 Access the Setting Menu
User could start to access the configuration menu anytime by opening a web
browser window by typing the IP address of this wireless router. The default IP
is 192.168.1.1.
Note: to configure the settings must through the wireless connection, instead of
RJ45 cable.
32
