HYDROMASSAGE JETS
LARGE HYDROMASSAGE Jets - This jet provides a unique, pulsating
massage. The water flow is adjustable in that it can be turned from low
to high (by rotating the jet faceplate ¼ turn).
MIDSIZE DIRECTIONAL JET - These jets allow you to redirect the
jet stream by changing the position of the nozzle. The water flow is
adjustable in that it can be turned from low to high (by rotating the jet
faceplate ¼ turn)
MIDSIZE ROTATIONAL JET - These jets provide a rotating massage
pattern. The water flow is adjustable in that it can be turned from low to
high (by rotating the jet faceplate ¼ turn)
Mini JET - These jets deliver a direct, more focused massage. The
water flow is adjustable in that it can be turned from low to high (by
rotating the jet faceplate ¼ turn)
WATERFALL VALVE
Your fitness system is equipped with
three waterfalls, two in the swim side
and one in the spa side. The left
illustrated valve is used in the swim
side. The flow is regulated by turning
the waterfall valves in either direction.
Jet pump 1 must be on for waterfall to run on spa side.
AIR CONTROLS
Your fitness system is equipped with two air valves. The
air valves will add or remove air to the hydromassage jet
system. Rotate valve to see which hydromassage jets are
affected.
SWIM MACHINE-HYDRAULIC
SWIM MACHINE OPERATION - Two remote controls have been
provided with your system and have
been packaged in the owner's packet
inside the equipment compartment
labeled Swim Current.
The swim machine is turned on
through the use of the remote control, which
also adjusts the speed of the current faster or
slower. When changing speed, you must press
and hold the buttons on the remote, then wait
a few seconds for the current to adjust. Upon initial start-up you will
find that the unit has been set to its lowest speed; which is a barely
perceptible current. You will need to press and HOLD the FASTER
button to increase the speed. Our standard pool’s top speed is roughly
equivalent to a 1:14/100 meters (1:08 100 yard) pace a speed for expert
swimmers only. Set the water speed at a comfortable level for your
needs. Remotes are waterproof but can not be submerged.
IMPORTANT: Starting up the swim machine will automatically turn OFF
the hydromassage jet system if ON, once swim machine is turned OFF
the hydormassage jet system will turn back ON.
To stop swimming, simply press the on/off button on the remote. If left
running, the power unit will turn off automatically after thirty minutes
and can be restarted by pressing the on/off button again. Once you
have found an optimal speed for yourself, you may leave the system
at that setting. The controller for the swim machine is designed with a
“ramp-up” feature which forces the swim machine to start slowly, but will
increase to the last setting at which someone swam.
When you are first learning to swim in the swim current, it is often useful
to allow yourself to drift back to the rear of the pool. Let your feet rest
on the rear seat and then swim forward into position. By starting from
the back, you can get a feel for just how much room you have. When
swimming, center your outstretched arm about one foot from the front grill
.
TREADMILL-HYDRAULIC (OPTIONAL)
TREADMILL OPERATION - Two remote controls have been provided
with your system and have been packaged in the owner's packet inside
the equipment compartment. These
remotes are identical to the swim machine
remotes but are labeled Treadmill.
Upon initial start-up you will find that unit
has been set to its lowest speed. You will
need to press and HOLD the FASTER
button to increase the speed.
The treadmill is turned on through the use of a remote control, which
also adjusts the speed of the treadmill faster or slower. When changing
speed, you must press and hold the buttons on the remote, then wait a
few seconds for the treadmill to adjust. Set the speed at a comfortable
level for your needs.
Remotes are waterproof but can not be submerged.
To turn off the treadmill, simply press the on/off button on the remote. If
left running, the power unit will turn off automatically after
thirty minutes and can be restarted by pressing the on/off button
again. The treadmill will always default to the slowest speed when
turned on.
When you are first learning to use the treadmill in conjunction with the
swim machine, it is best to start at the lowest speeds for both the swim
machine and treadmill. The added resistance the swim machine offers
may allow for a slower treadmill speed then initially thought.
IMPORTANT: Do not use treadmill when circulation pump is OFF.
