Endless Pools X2000 SwimCross - GETTING STARTED; MAIN EXERCISE SYSTEM FEATURES; ADDITIONAL EXERCISE SYSTEM FEATURES

Page 10
Getting Started
MAIN EXERCISE SYSTEM FEATURES
12) Swim Side Speaker
(Optional)
13) Spa Side Speaker
(Optional)
14) Suction Screen
15) Water feature
16) Ozone Jet
17) Heater Return
18) Grab Rails
19) Filter Compartment
20) Points of light
21) Row Bar Anchor
22) Tether Anchor
ADDITIONAL EXERCISE SYSTEM FEATURES
Your exercise system may look slightly different than the illustration
1 ) Two control panels are used to provides a quick
visual check of the
exercise system ’s status and
allows the user to set different functions in both the
swim and spa sides.
2) The Air Valve allows you to add air to your spa
side hydromassage jets.
3) Spa side Water Feature Levers adjust the amount
of water that flows from the water features. Jet pump
1 must be on for water feature to work.
4) Swim side Water Feature Levers adjust the
amount of water that flows from the water features.
5) The Swim jets provide a strong flow of water
creating a current to swim against.
6) The Large Hydromassage jets provide a unique,
pulsating massage on the spa side.
7) The Midsize Directional Hydromassage jets,
with eyeball nozzles, deliver a direct, more focused
massage on the spa side.
8) The Midsize rotational Hydromassage jets,
provide a rotating massage on the spa side.
9) The Mini Hydromassage jets feature a direct
more focused massage on the spa side.
10) Pillow (spa side)
11) Main Swim Light (swim side)
1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15 15
16
17
18
18
19 19
19
21 21
22
14
Getting Started
18
