Levelflex FMP56, FMP57 FOUNDATION Fieldbus Operating menu
Endress+Hauser 143
17.3.1 "Mapping" wizard
The Mapping wizard is only available when operating via the local display. When
operating via an operating tool, all parameters concerning the mapping are located
directly in the Setup menu (→  137).
In the Mapping wizard two parameters are displayed simultaneously on the display
module at any one time. The upper parameter can be edited, whereas the lower
parameter is displayed for reference purposes only.
Navigation  Setup → Mapping
Confirm distance 
Navigation  Setup → Mapping → Confirm distance
Description →  140
Mapping end point 
Navigation  Setup → Mapping → Map. end point
Description →  141
Record map 
Navigation  Setup → Mapping → Record map
Description →  142
Distance
Navigation  Setup → Mapping → Distance
Description →  139
