8.3 Dimensions Prowirl 77 H
ba037y41
Flanges according to:
• DIN 2501, raised face
acc. to DIN 2526 form E
• ANSI B16.5
• JIS B2238
Fig. 17
Dimensions of Prowirl 77 H
DN Standard Pressure
rating
d
[mm]
D
[mm]
H
[mm]
L
[mm]
X
[mm]
Weight
[kg]
15 / ½"
DIN PN 160 17.3 105
288 200 22.4
7
ANSI SCHED 80 Cl. 600 13.9 95.3 6
JIS SCHED 80 Cl. 40K 13.9 115 8
25 / 1"
DIN
PN 100
PN 160
28.5
27.9
140
140
295 200 26.4
11
11
ANSI SCHED 80 Cl. 600 24.3 124 9
JIS SCHED 80 Cl. 40K 24.3 130 10
40 / 1½"
DIN
PN 100
PN 160
42.5
41.1
170
170
303 200 30.9
15
15
ANSI SCHED 80 Cl. 600 38.1 155.4 13
JIS SCHED 80 Cl. 40K 38.1 160 14
50 / 2"
DIN
PN 64
PN 100
PN 160
54.5
53.9
52.3
180
195
195
310 200 32.4
17
19
19
ANSI SCHED 80 Cl. 600 49.2 165.1 14
JIS SCHED 80 Cl. 40K 49.2 165 15
80 / 3"
DIN
PN 64
PN 100
PN 160
81.7
80.9
76.3
215
230
230
323 200 38.2
24
27
27
ANSI SCHED 80 Cl. 600 73.7 209.6 22
JIS SCHED 80 Cl. 40K 73.7 210 24
100 / 4"
DIN
PN 64
PN 100
PN 160
106.3
104.3
98.3
250
265
265
335 250 48.9
39
42
42
ANSI SCHED 80 Cl. 600 97 273.1 43
JIS SCHED 80 Cl. 40K 97 240 36
150 / 6"
DIN
PN 64
PN 100
PN 160
157.1
154.1
146.3
345
355
355
359 300 63.4
86
88
88
ANSI SCHED 80 Cl. 600 146.3 355.6 87
JIS SCHED 80 Cl.40K 146.6 325 77
