8.4 Dimensions Flow Conditioner (DIN)
ba037y25
Material
316L (1.4435)
Fig. 18
Dimensions flow conditioner
DIN
DN Pressure rating Centering
diameter
[mm]
D1 / D2 s Weight
[kg]
15
PN 10...40
PN 64
54.3
64.3
D2
D1
2.0
0.04
0.05
25
PN 10...40
PN 64
74.3
85.3
D1
D1
3.5
0.12
0.15
40
PN 10...40
PN 64
95.3
106.3
D1
D1
5.3
0.3
0.4
50
PN 10...40
PN 64
110.0
116.3
D2
D1
6.8
0.5
0.6
80
PN 10...40
PN 64
145.3
151.3
D2
D1
10.1
1.4
1.4
100
PN 10/16
PN 25/40
PN 64
165.3
171.3
252.0
D2
D1
D1
13.3
2.4
2.4
2.4
150
PN 10/16
PN 25/40
PN 64
221.0
227.0
252.0
D2
D2
D1
20.0
6.3
7.8
7.8
200
PN 10
PN 16
PN 25
PN 40
PN 64
274.0
274.0
280.0
294.0
309.0
D1
D2
D1
D2
D1
26.3
11.5
12.3
12.3
15.9
15.9
250
PN 10/16
PN 25
PN 40
PN 64
330.0
340.0
355.0
363.0
D2
D1
D2
D1
33.0
25.7
25.7
27.5
27.5
300
PN 10/16
PN 25
PN 40/64
380.0
404.0
420.0
D2
D1
D1
39.6
36.4
36.4
44.7
Explanation of entries in column D1 / D2:
D1: The flow conditioner is clamped between bolts at its outer diameter.
D2: The flow conditioner is clamped between bolts at the indentures.
