5.6 Prowirl 77 Slot / Index list
Basis is the definition of Profiles by the PROFIBUS user organisation (PNO).
All parameters (except for the totalizer block) are positioned in Slot 1.
The index can be found in the following table:
Note!
Additional information
regarding the following
tables can be found in
“PROFIBUS-PA Profile for
Process Control Devices;
General Requirements
V2.0”.
Name E+H
Matrix
Index Read Write * Para-
meter
Data type Size
bytes
Storage
Class
Device Management
Directory Object
Header
0 X M Unsigned16 12 C
Composite List
Directory Entries
1 X M Unsigned16 28 C
not used 2...13
Physical Block (PB)
PB Block Object 14 X M DS-32 20 C
PB Static Revision 15 X M Unsigned16 2 N
PB Tag Description VAH0 16 X X M Octet String 32 S
PB Strategy 17 X X M Unsigned16 2 S
PB Alert Key 18 X X M Unsigned8 1 S
PB Target Mode 19 X X M Unsigned8 1 S
PB Mode Block 20 X M DS-37 3 N/Cst
PB Alarm Summary 21 X M DS-42 8 D
PB Software Revision V5H4 22 X M Octet String 16 Cst
PB Hardware Revision V5H5 23 X M Octet String 16 Cst
PB Device
Manufacturer ID
24 X M Unsigned16 2 Cst
PB Device ID 25 X M Octet String 16 Cst
PB Device Serial
Number
VAH1 26 X M Octet String 16 Cst
PB Diagnosis 27 X M Octet String 4 D
PB Diagnosis Extension 28 X O Octet String 6 D
PB Diagnosis Mask 29 X M Octet String 4 Cst
PB Diagnosis Mask
Extension
30 X O Octet String 6 Cst
PB Device Certification 31 X X O Octet String 16 N
PB Security Locking 32 X X O Unsigned16 2 N
PB Factory Reset 33 X X O Unsigned16 2 S
not used 34...43
PB Descriptor 44 X X M Octet String 32 S
PB Device Message 45 X X M Octet String 32 S
PB Device Installation
Date
46 X X M Octet String 8 S
not used 47...51
PB Actual Error Code V5H2 52 X O Unsigned16 2 D
PB Last Error Code V5H3 53 X X O Unsigned16 2 D
PB UpDown
Features Supported
54 X M Octet String 1 Cst
PB UpDown
Control Parameter
55 X X O Unsigned8 1 D
PB UpDown Parameter 56 X X O UpDownData 20 D
PB Device Bus Address V5H0 57 X O Signed8 1 D
PB Device &
Software Number
58 X O Unsigned16 2 Cst
not used 59...64
Transducer Block (TB) Flow
TB Block Object 65 X M DS-32 20 C
TB Static Revision 66 X M Unsigned16 2 N
TB Tag Description 67 X X M Octet String 32 S
TB Strategy 68 X X M Unsigned16 2 S
Note!
