Battery Charger RX
User's Manual
CHARGE OPERATIONS
• The maximum time allowed to reach the gassing voltage is 12 hours. If the battery doesn’t
reach the gassing voltage within 12 hours the charger stops and the LED “EMERGENCY
STOP” lights on and the EQUALIZATION is excluded.
• When the battery reaches the gassing voltage, the LED “FINAL CHARGE” starts to flash,
together with the LED “CHARGE ON”, and the charge continues for 3 hours.
• If the battery is disconnected, the charger turns off in 3 seconds and the charge process is
completely reset.
• When a battery is re-connected, the charger turns on automatically and the charge starts
from the beginning.
• If, during the charge or equalization, there are one or more black-outs of the mains, the
microprocessor keeps in memory the state of the charge and, when the power supply is
available again, the charge re-starts from the exact point of interruption.
• When the charge is complete, the charger goes in stand-by mode for 15hours 30minutes,
before to proceed with the equalization, therefore the equalization will be executed only when
the charger remains connected for more than 24hours (normally in the weekend).
• The equalization consists in 4 small charge cycles (30 minutes long), with 15hours and 30
minutes of interval between each cycle. During extra charge cycles the LEDs “ FINAL
CHARGE” and “STOP-100%” flash alternately.
END OF CHARGE
When the battery is completely charged the charger is turned off and the LED “STOP – 100%”
continues to flash.
OWM-040906-RX Version: 02-AB Page 20 of 25
NOTE
The operations described in this chapter are done by ENERGIC Plus RX chargers
automatically.
WARNING !
Before disconnecting the battery, make sure that it is not being charged. If it is being
charged, turn off the charger using the STOP pushbutton, to avoid sparks between
connectors.
