14
Table 2.4
Specification name Specification value Note
Base (max.) currents 5(60); 5(100) А Direct connection
Nominal phase voltage 230 V
Operating phase voltage (0.55...1.21) U
nom
V
Nominal network frequency (50±2.5) Hz
Non-sinusoidal factor of the measuring
network voltage, %, max
–
In accordance with
EN50160:2010
Sensitivity threshold 0,002 Ib
Number of decimal places on the LCD from Table 2.1
Apparent power consumed by each
current circuit, max
0.3 (V•A) for version Q
0.05(V•A) for others
With nominal (base) current
Apparent (active) power (consumed by
voltage circuit at nominal voltage, max
9(V•A) (1.1 W) With nominal voltage
Active power consumed by the built-in
communication modules at the nominal
voltage value, max, W
3 W
For versions with
communication modules
Limit of the clock basic absolute error ± 0.5 s/day
Manual and system correction, clock rate ± 29 s Once a day
