10 LABELING
10.1 Information applied to the front panel of the meter by offset printing or in another way not degrading the
quality:
– meter type designation — CE208;
– accuracy class according to IEC 62052-11:2003, IEC 62053-21:2003 and IEC 62053-23:2003;
– meter constant in accordance with Table 2.3;
– a bar code
8
including the year of manufacture, the number of the meter and other additional information;
– nominal voltage;
– base and max. current;
– frequency 50 Hz;
– the number of phases and the number of wires in the circuit for which the counter is intended, as a graphic
symbol in accordance with GOST 25372-95;
– trademark of the manufacturing enterprise ENERGOMERA;
– IEC 62052-11:2003, IEC 62053-21:2003 and IEC 62053-23:2003.
– measuring instruments approval type sign image;
– the image of the common EAC circulation mark when receiving the certificate;
– a double square sign
for meters of protection class II placed into an insulating housing;
insulation testing voltage (C2 symbol as per GOST 23217-78);
– inscription – RUSSIA;
– interface type in accordance with the structure of meter designation given in clause 2.2;
– labeling of controls «FRAME», «VIEW», «ACCESS».
The meter activation diagrams are given on the cover of the clamping block or on the meter’s front panel. On the
cover of the clamping block there is an «Attention» sign (
) – according to GOST 23217-78.
8
The barcode of split metering devices is applied by laser printing and is weatherproof during the service life of the device.
