СЕ 208 S7.Х4Х.Х.OХ.XXXX XXX
Designation of the integrated communication module
Additional functions:
See Table 2.3.
Integrated communication interfaces:
See Table 2.2.
Number of measuring elements:
1 – meter with one current sensor (in the phase circuit);
2 – meter with two current sensors (in the phase and neutral circuits);
Nominal or base (max.) current:
5 – 5(60) А;
6 – 5(100) А.
Nominal voltage (phase/line):
4 – 3x230/400 V.
Active/reactive energy accuracy class:
8 – 1/2 for active/reactive energy;
7 – 1/1 for active/reactive energy.
Body type and number:
S7 – for 3 screws mounting
Figure 2.1 – Designation structure
