Table 4.1
Counting mechanism and
display window position
Display window
Power transformation ratio
(K
P
=K
V
-K
C
)*
109876 54321.123 45
54321.123 kW•h up to 10
10987 654321.12 345
654321.12 kW•h from 10 to 100
1098 7654321.1 2345
7654321.1 kW•h from 100 to 1000
109 87654321 .12345
87654.321 MW•h from 1000 to 10000
10 98765432 1.12345
987654.32 MW•h from 10000 to 100000
1 09876543 21.12345
0987654.3 MW•h from 100000 to 1000000
10987654 321.12345
10987.654 MkW•h from 1000000 to 10000000
* KV — transformation ratio of a measuring voltage transformer
KC — transformation ratio of a measuring current transformer
Note: In the electricity metering mode, when the readings are constantly changing, there may be a discrepancy
between the readings due to non-simultaneous viewing.
4.1.1 A complete list of output formats of measured, calculated and accumulated parameters is given in Table 4.2.
