38
Table 4.2
Name of output
parameters
To LCD By interfaces
Measurement
units
Number of
digits left/right
of the point
Measurement
units
Number of digits
left/right of the
point
Voltage V 4 digits V /3
Current А 4 digits А /4
Active power W-kW 4 digits kW /5
Reactive power Var-kVar 4 digits kVar /5
Apparent power VA-kVA 4 digits kVA /5
Power factor /3 /3
Angle between current and
voltage
◦
/1
◦
/1
Network frequency Hz /2 Hz /2
Active energy on an accrual
basis (monthly, daily accumula-
tion)
kW•h
6/2
For transformer
versions, also see
Tables 2, 3
kW•h /5
Reactive energy on an accrual
basis
kVar•h kVar•h /5
Averaged power values of the
load profiles
kW /5
