EngA AF Series - Refrigeration Piping Materials and Procedures; Tubing Specifications and Preparation

A
AF / DCU MANUAL
IOM-52 15 of 23 Apr 13 R2

REFRIGERATIONPIPINGMATERIALSANDPROCEDURES

Note:

Aqualifiedrefrigerationcontractorexperiencedinrefrigerantpipingmustcompletethe
installation.Theinstallationmustbecompletedusingindustry‐acceptedmethodsand
materials.

WARNING:

TheAFunitisshippedwithaholdingchargeofdrynitrogen.
Thispressureshallbereleasedsafelybeforeopeningsystemorconnectingtubing.
TUBING
UseNitrogenizedACRgrade,‘TypeL’or‘TypeK’coppertubingonly.Allrefrigeranttubingshallbeclean
anddry.Thetubingshallbenitrogenpurgedduringthebrazingprocess.Thispreventsharmfulcopper
oxidesfromforminginthetubing.

WARNING:

Nitrogencylindersshallbeequippedwithahigh‐pressureregulatorandflowmeter.Do
notconnecthigh‐pressurecylinderstotherefrigerantcircuitwithoutaregulator.
Failuretodosomayresultinpropertydamage,injuryordeath.

Refrigeranttubingmustbecutwithatubecutterandtheendsdeburredbeforeinstallation.Neverusea
hacksaworabrasivecuttertocutrefrigerationtubing.

Longradiuselbowsshouldbeusedtoreducepressuredrop.

CoppertocopperconnectionsshouldbemadewithSILFOS,orsimilarsilverbearinglowtemperature
brazingmaterial.

Coppertobrassorcoppertosteeljointsshouldbemadewith45%silversolderandtheappropriateflux.
Fluxmustbecleanedfromtubingafterinstallation.

WARNING:

Softsolders(50/50,95/5,etc)arenotsuitableforusewithairconditioningsystems.

Allaccessoriesshallbeproperlyprotectedfromheatduringinstallation.Refertotheinstallationguidelines
suppliedwiththecomponents.Itispreferredtoinstallthefilter/drierlasttoavoidextendedexposureto
atmosphere(moisture).

Pipingshallbeproperlysupportedandallowancesshallbemadeforthermalexpansionorcontractionof
tubing.
