LEAKCHECKING
Afterinstallation,alljoints,bothfactoryandfieldinstalled,shallbepressurecheckedandleaktestedusing
approvedindustrymethods.

WARNING:

Testpressuresmustnotexceedthemaximumpressureratingsspecifiedontheunit
ratingplate.

WARNING:

OxygenmustNEVERbeusedtopressurizeasystem.
Ensureallservicevalvesandmanualvalvesareopen.Ifleaksarelocated,removepressureandrepair
leaks.Recheckasnecessary.

Ifbrazingisnecessarytorepairleaks,adrynitrogenpurgethroughtubingwhilebrazingisrequiredto
preventtheformationofcopperoxides.
EVACUATIONANDDEHYDRATION
Thesystemmustbeevacuatedpriortocharging.Properevacuationwillremovenon‐condensablegasses
andwatervaporfromthesystem.Watervaporinthesystemwillcombinewiththeoilandrefrigerantto
formacidsandotherundesirableby‐products.Non‐condensablegassessuchasairornitrogenwill
increasetheheadpressureandoperatingtemperatureanddegradesystemperformance.

Sketchapipingschematicshowingallvalvesandcomponents.Checkthediagramtoensurethatall
portionsofthesystemwillbeevacuated.Addadditionalhosesorservicefittingsasrequired.

Note:

Ahighvacuumcannotbepulledthroughasolenoidvalvewhetherornotitisenergized.
Ahighvacuumcannotbepulledthroughacheckvalveregardlessofdirectionofflow.

EvacuationProcedure:
1. Removeleak‐testinggassesfromthesystem.Ifrefrigerantwasusedtoleaktest,therefrigerant
shallberecovered.
2. Connectahighvacuumpumptothesystem.Usetheshortestandlargestdiameterhoseavailable.
3. Useasmanyconnectionsasthesystemwillallow.
4. Ifevacuatingthrough‘Schraedervalves’,removetheSchraedervalvecorebeforeevacuation.
5. Openallservicevalves.
6. Useamicrongaugetomeasurethevacuum.

Note:

Astandardrefrigerationgaugewith“inchesofmercury”isnotsuitabletomeasurethehigh
vacuums.AhighvacuumgaugecapableofmeasuringMicronsisrequired.
