Thesketchbelowdescribesaboveandbelowpipingconnectionsandtraprequirements.Onlyinstall
reducersontheverticalline,atleast12”(300mm)belowtheheaderconnection.


*12”(300mm)minimumheightbeforereducingsize.

REFRIGERATIONSPECIALTIES(BYOTHERS)

Note:

Refrigerantspecialtiesareselected,suppliedandinstalledbytheinstallingcontractor.
Mostofthesedeviceshavespecifieddirectionsofflowandmaybepermanentlydamagedif
notinstalledcorrectly.Alwaysfollowtheinstallationinstructionsprovidedwiththe
components.
SERVICEVALVES(Recommended)

Servicevalvesshouldbeinstalledtoallowservicingoftheequipment.Aliquidlineservicevalveatthe
condensingunitisconsideredaminimumrequirement.
SIGHTGLASS/MOISTUREINDICATOR(Required)

Sightglassesareinstalledintheliquidlinetogiveavisualindicationofthe
refrigerantcharge.Themoistureindicatorgivesanindicationofthemoisture
contentoftherefrigerant.
LIQUIDLINEFILTER‐DRIER(Required)

Thefilter‐drierisinstalledintheliquidlinetofilterparticulateandforeignmatter
fromtherefrigerant.Filter‐driersalsoabsorbsmallamountsofmoistureandacid.
