ELECTRICAL
 Checkallwiringforlooseconnections.
 Checkvoltageatunit(whileinoperation).
 Checkamperagedrawagainstunitratingplate.
 Wherepossible,allcontactorsshouldbeinspectedtoensurethatcontactsarecleanandare
makinggoodcontact.Ifcontactsareabnormallypittedorburnedbadly,replacecontactor.Single
phasingandmotorburnoutscanresultfrombadcontacts.

BELTADJUSTMENT
Formaximumbeltandbearinglife,pulleyalignmentandbelttensionmustbeproperlymaintained.Only
replacewithbeltsofthepropertypeandsize.

NOTE:Ifbeltsaretootightorimproperlyaligned,thelifeexpectancyofthemotor(s),fanbearingsand
belt(s)arereduced.

Alignment: Pulleysmustbealignedtowithin1/16”perfoot(1mmper760mm)ofspan.

BeltDeflection: Allow1/64”(0.4mm)ofdeflectionforeach1”(25.4mm)ofspanlength.


CAUTION:

Excessivebelttensionisthemostfrequentcauseofbeltwear,bearingwearandnoise.

SETSCREWS
Checksetscrewsonfanwheel,fanbearings,fanandmotorpulleysforloosenessontheshaft.Tighten
whererequired.Itisimportanttoperformthischeckbeforeinitialstart‐up,afterarun‐inperiodof2
weeksandthenon4monthintervals.

CAUTION:

Overtighteningsetscrewscandamagebearings.




DEFLECTION
S
P
A
N
