Front Panel
A. LED Lights
LED lights for Power, Gigabit Ethernet port, WLAN 2.4GHz and WLAN 5GHz
Rear Panel
B. Power
12V DC IN for Power.
C. Gigabit Ethernet Port
802.3at PoE Gigabit Ethernet port for RJ-45 cable.
D. Reset Button
One click for reset the device. Press over 10 seconds for reset to factory default.
Kingston Security Slot
To protect your ECB1750, attach on a cable lock.
