EnGenius ENS620EXT - WDS Bridge Mode

28
WDS Bridge Mode
InWDSBridgeMode,theAccesssPointcanwirelesslyconnectdifferentLANsbyconguringtheMACaddressandsecurity
settingsofeachAccessPoints.UsethisoperatingmodewhentwowiredLANslocatedasmalldistanceapartwantto
communicate with each other. The best solution is to use the Access Point to wirelessly connect two wired LANs, as
shown in the following diagram.
WDSBridgeModecanestablishuptofour(4)toeight(8)WDSlinks,creatingastar-likenetwork.
Note: WDS Bridge Mode does not act as an Access Point. Access Points linked by WDS are using the same frequency
channel. More Access Points connected together may lower throughput. This conguration can be susceptible to
generate endless network loops in your network, so it is recommended to enable the Spanning Tree function to
prevent this from happening.
AP
WDS Bridge
AP
WDS Bridge
AP
WDS Bridge
Client
Computer
Client
Computer
Client
Computer
