Datasheet
M5000
BUSINESS CLASS
M5000
M5000 Datasheet Version 02032010
*Theoretical wireless signal rate based on IEEE standard of 802.11 a, b, g chipset used. Actual throughput may vary.Network conditions and environmental
factors lower actual throughput rate.
** All specifications are subject to change without notice
TECHNICAL SPECIFICATION
> Hardware Specification
MCU/RF Atheros AR2313+AR5112
Memory 32MB SDRAM
Flash 8MB
Physical Interface 1 x 10/100 Fast Ethernet RJ-45
LED indicators Power/ Status
Power Requirements Active Ethernet (Power over Ethernet) Proprietary PoE design
Regulation Certifications FCC Part 15C/15B/15E, EN301 893, EN 300 328, EN 301 489-1/-17, EN60950, IC
> RF Specification
Frequency Band 802.11a = 5.150~5.350GHz, 5.470~5.725GHz, 5.725~5.825GHz
Modulation Technology OFDM = BPSK, QPSK, 16-QAM, 64-QAM
Operating Channels 802.11a = See the Table1
Receive Sensitivity (Typical)
802.11a
-92dBm @ 6Mbps,
-73dBm @ 54Mbps
802.11g
-92 dBm @ 6Mbps,
-75 dBm @ 54Mbp
802.11b
-97 dBm @ 1Mbps
-91 dBm @ 11Mbps
Available transmit power (Average
power)
FCC ETSI
Frequency Power Frequency Power
5.150~5.350 GHz
IEEE802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5.150~5.350 GHz
IEEE802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5.470~5.725 GHz
IEEE802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5.470~5.725 GHz
IEEE802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5.725~5.825 GHz
IEEE802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5.725~5.825 GHz
IEEE802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
2.412~2.462 GHz
IEEE802.11g
26dBm@6~24Mbps
24dBm@36Mbps
23dBm@48Mbps
22dBm@54Mbps
2.412~2.472 GHz
IEEE802.11g
26dBm@6~24Mbps
24dBm@36Mbps
23dBm@48Mbps
22dBm@54Mbps
2.412~2.462 GHz
IEEE802.11b
27dBm@1~11Mbps
2.412~2.472 GHz
IEEE802.11b
27dBm@1~11Mbps
Antenna Specification
Gain 14dBi
Radiation Directional
Frequency Band Range 5.1-5.8GHz
Horizontal -3dB Bandwidth 35
O
Internal Antenna
(Dual Polarization)
Vertical -3dB Bandwidth 15
O
