4.12. Configuration via easyWallbox Up! (service app)
The final configuration for installation in Mode 3 should be done via the
purpose-built app, easyWallbox Up!, only available for Android devices
from Google Play.
In detail, qualified personnel who install in Mode 3 should authenticate
this, thus unlocking access to safety-relevant configuration parameters.
The most important for correct operation is the safety limit on current
absorption from the supply. Be aware that easyWallbox will not charge
EVs plugged in Mode 3 unless properly configured in accordance with
the following directions via the app.
The maximum charging current in Mode 3 or Mode 2 with Power
Upgrade (‘ Safety limit’ ) must be the minimum value between the:
⚫ current allowed by the installed power supply, including wiring
sections
⚫ current allowed by local applicable standards.
The following table contains indicative values of maximum currents for
each installation country, to be checked however before any installation:
Country
Current limit
Country Current limit
with Power
Upgrade [A]
with Power
Upgrade [A]
1. Germany
20
11. Czech Republic 25
2. France
32
12. Slovakia 20
3. UK
32
13. Hungary 32
4. Belgium
22
14. Denmark 16
5. Luxembourg
32
15. Sweden 32
6. Netherlands
22
16. Italy 26
7. Switzerland
16
17. Spain 32
8. Austria
16
18. Portugal 32
9. Poland
32
19. Norway 32
10. Greece
32
1. Open easyWallbox Up! on your smartphone.
2. Authenticate with your qualified personnel credentials.
3. Scan the authentication QR code available (see chapter 5.2)
4. Enter the ‘Safety limit’ determined according to the above
instructions. This must comply with local applicable regulations and
consistent with the maximum current allowed by the supply wiring.
5. If easyWallbox is configured with the rotary switch (U14) in position 2,
the app defines whether DPM is enabled:
a. If you did not install the sensor in accordance with section 4.9,
set ‘DPM’ to Off.
b. If you installed the sensor in accordance with section 4.9, set
‘DPM’ to On and ‘DPM limit’ in accordance with the user’s
energy supply contract.
6. Make sure that the ‘User limit’ is set to a value lower than or equal to
‘Safety limit’ and compatible with the user’s energy supply
contract.
If the instructions in this paragraph are not followed, all parameters
remain as initially set for Mode 2. This reduces easyWallbox’s
performance.
The installation and parameter set-up should be in accordance
with local applicable standards. Please check local updates of
standards before setting up parameters.
