55MIDICHANNEL&VOL.0
Atipfromthedesigner:
Use this setof encodingbuttons (1, 2, 3,4 and 5) to assignthe MIDI channel. This tells
the amp's MIDI system over which channel it will receive MIDI program change
commands. Your choices are the standard 16 MIDI channels (numbered from 00 to
15), as well as OMNI mode (whereby all MIDI data is received regardless of the MIDI
send channel). The encoding button settings for a specific channel and OMNI mode
arelistedinthefollowingtable.
Encoding button number 6 lets you program the amp so that it is muted when it
receives a MIDI controller 7 command. When this command has a value of 0 (and less
than and equal to 5), the amp's master volume is muted. At values greater than or
equal to 5, the amp is back on line at the volume level determined by the currently
activeMasterknob.
Setting the encoding button to ON activates Master Volume Mute.
Setting the encoding button to OFF deactivates Master Volume Mute.
MIDI channel assignment using the encoding buttons:
MIDI-channel: S1 S2 S3 S4 S5 S6
OMNI OFF XX XX XX XX XX
CH1 ON OFF OFF OFF OFF XX
CH2 ON OFF OFF OFF ON XX
CH3 ON OFF OFF ON OFF XX
CH4 ON OFF OFF ON ON XX
CH5 ON OFF ON OFF OFF XX
CH6 ON OFF ON OFF ON XX
CH7 ON OFF ON ON OFF XX
CH8 ON OFF ON ON ON XX
CH9 ON ON OFF OFF OFF XX
CH10 ON ON OFF OFF ON XX
CH11 ON ON OFF ON OFF XX
CH12 ON ON OFF ON ON XX
CH13 ON ON ON OFF OFF XX
CH14 ON ON ON OFF ON XX
CH15 ON ON ON ON OFF XX
CH16 ON ON ON ON ON XX
As the table indicates, encoding button 1 switches between Poly and OMNI mode.
Bear this in mind for practical applications, because this is a fast way to go from a
presetPolychanneltoOMNImodeandviceversa.
