enphase IQ Combiner 5 Quick Install Guide

Section A
Mounting the Product
Plan a location for the
IQCombiner5/5C
• IQCombiner5/5C is NEMA type 3R rated and can be mounted both indoors and outdoors.
Install the unit where it is not exposed to direct rainfall.
• Install this product where cables from PV, grid, and IQBattery are easily accessible and can be wired
to the IQCombiner 5C.
8,530ft
+46°C
-40°C
• This product is designed to be installed on a vertical wall only. Do not install this product at on the
ground. The product must be mounted within 15° of vertical.
• The mounting surface must be able to support 16.5 lbs.
• Follow all local standards and regulations during installation.
• The product operates within an ambient temperature range from -40°C to 46°C.
• Do not install this product in a place where it is directly exposed to sunlight.
• Do not install the product in a very dusty environment.
• This product must not be installed at altitudes above 8,530 ft (2,600 m).
• In ood-prone areas, ensure that the clearance from the ground is sucient to avoid water ingress.
IQ Combiner 5/5C Quick Install Guide13
