© 2019 Enphase Energy Inc.
WARNING: Risk of equipment damage. Do not connect the AC connector until the DC
connector is completely engaged.
NOTE: This action connects the internal battery to the internal electronics; you must
disconnect it if you move or transport the AC Battery.
NOTE: Check to ensure that the wall-mount bracket junction box is fully inside the access
compartment of the AC Battery. The AC Battery must not rest on the junction box or rely on it
for support.
f. Connect the battery AC connector into the AC connector on the junction box. Listen for a clicking
sound as the connectors engage.
g. Attach the bottom access plate and secure the two compression half-turn latches using a 4mm Allen
key.
6. Energise and Commission the System
WARNING: Before energizing the system, check to ensure that ALL of the AC batteries in the
system are properly installed and conductors terminated.
a. Check to ensure that the AC Battery bottom access plates on all AC batteries in the system are
closed and secured.
b. Switch on the circuit feeding the AC Battery(ies).
c. The AC Battery LED should flash yellow for the duration of the start-up process. If the LED does not
flash yellow, see the corresponding section under Troubleshooting.
d. Use the Enphase Installer Toolkit to commission the AC Battery(ies). Once connected to the Envoy,
refer to the Installer Toolkit help topics for more information.
e. After the Envoy-S has detected the AC Battery(ies), the AC Battery LEDs operate as described in the
following section.
