enphase IQ7-B1200-LN-I-INT01-RV0 - Technical Data

© 2019 Enphase Energy Inc.
24
Technical Data
Model Number
Enphase AC Battery
IQ7-1200-LN-I-INT01-RV0
Accessories
Enphase wall-mount bracket
Order separately:
BWM-450MM-A: 450 mm (W) x 311 mm (H)
BWM-600MM-A: 647 mm (W) x 311 mm (H)
Input / Output Data
Peak input / output power
270 VA
Rated (continuous) output power
260 VA
Extended line to neutral voltage range
184 to 276 VAC
Nominal frequency
50 Hz
Extended frequency range
45 to 55 Hz
Power factor (adjustable)
1.0 / 0.7 leading to 0.7 lagging
Maximum units per 20 A branch circuit
13
Peak inverter efficiency
96.9%
Battery Chemistry
Capacity
1.2 kWh
Depth of discharge (usable capacity)
100%
Ambient temperature range
-20ºC to 45ºC
Chemistry
Lithium Iron Phosphate (LFP)
Cell safety certifications
TUV Rheinland
Roundtrip cell efficiency
1
96%
Mechanical Data
Dimensions
390 mm (W) x 325 mm (H) x 220 mm (D) (without bracket)
Weight
23 kg
Installation
Wall-mounted in an indoor space using standard AC wiring in conduit or in wall,
where allowed.
Enclosure
Indoor – IP20
Cooling
Natural convection: No active or passive cooling infrastructure required
Grid configuration
TN-C-S
Features and Compliance
Compatibility
Compatible with grid-tied PV systems using the Enphase Envoy-S™ Metered gateway.
Communication
Power Line Communication (PLC), TCP/IP through Envoy-S
2
.
Services
Maximising self-consumption of solar, time-of-use bill management, power export
limiting
3
Monitoring
Enlighten Manager and MyEnlighten monitoring options
Compliance
IEC 62109-1, IEC 62109-2, IEC 62619, G59/3, G83/2; UN 38.3, VDE 0126-1-1, VDE-AR-N
4105
1
At 30°C
2
With software version 4.10
3
Optional. Requires Enphase S/IQ-Series Microinverters to implement.
