Overview
1-2
Figure 1-1 The Matrix E7 6C107 Chassis with Redundant Power Supplies
3280-01-01
PS1 PS2
Module Slots (7 Total)
SERIES E7
4 5
6
7
1
2 3
Chassis
(6C107)
Fan Tray
(6C407)
Redundant Power
Supplies (2) (6C207-1)
50/60Hz
LINE
100-125V~12A
200-240V~6A
AC ON
ACON
1
0
POWER FAN
50/60Hz
50/60Hz
LINE
LINE
100-125V~12A
200-240V~6A
AC ON
ACON
1
0
POWER FAN
